Hi,

Last month i bought the new BMS from vectrix and Jorge Rocha from e-mobilidade has been working to install this BMS.

But he has some problems to install this BMS because the temperature sensors..

At the moment, he install thermistors but this solution doesn't work fine..

1 - Low cell give me always 000

2 - Vectrix doesn't charge above 142

3 - Vectrix doesn't charge more than 6A

4 - Vectrix give me some errors (for example, the battery warning)

5 - A sensor give me the correct value and number 1, but number 2 and 4 give me 1degree and number 3 give me 45degrees.

It is possible to temporarily turn off the bms temperature sensors?

Thanks Piotr,

I instal a virtual machine with win Xp 64bits, the aplications install with sucess, but the vectrix icon (to run the aplication) doesn t appear..

Hi,

i try ran Vectrix diagnostic but the software doesn't run..

I have windows 10.

I install the peak can bus drivers and turn of the antivirus and firewall.

But nothing results..

Any suggestion?

Regards

I have the same bms and the same problem..

For example, in the begin the low cell have 000v, and the hi have 3.93v, and bms needs minutes to update the low cell value.

Vectrix stop to charge when she have 144V..

The BMS cooler doesn't stop when the Vectrix is off..

The old sensors doesn't work with this new BMS..

I have li ion pack

Thanks

Hi, when i am installing the firmware the status are red with the message 'can bus fault' and i can't install the ICM (red field with N/A)

Can help me?

Best regards
